Til Angled Abutment

A 15° angled titanium abutment for the Til implant, to correct the implant axis when it is not parallel to the planned restoration.

Key features

• 15° angulation
• Supplied with abutment screw TPAS
• Maximum recommended torque: 25 Ncm

Sizes and references

Select angle above. Each combination has its own reference code (SKU), listed below.

How to choose

Choose an angled abutment when the implant axis differs from the desired crown axis by about the available angle.

Compatibility

Designed for the Til internal-hex implant (Ø3.0 mm platform). Do not combine with components of another MSDI system; each system has its own connection geometry.

Regulatory

MSDI products meet the highest standards set by the FDA, CE MDR, ISO 13485 and other regulatory bodies. Some products may not have regulatory clearance for sale in specific territories. See the instructions for use (IFU).

Frequently asked questions

Which implant does this fit?

The Til internal-hex implant (Ø3.0 mm platform) only. Components from other MSDI systems are not interchangeable.

Where can I find instructions for use?

The IFU for all MSDI products is available at eifu.msdi-dental.com. Always read it before use.
